| DONANIM ÖZELLİKLERİ |
|---|
| İşlemci | Qualcomm 560MHz CPU, MIPS 74Kc |
|---|
| Bellek | 64MB DDR2 RAM,8MB Flash |
|---|
| Arabirim | 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button |
|---|
| Güç Kaynağı | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC |
|---|
| Boyutlar ( W X D X H ) | 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.) |
|---|
| Anten Kazancı | 23dBi |
|---|
| Anten Beamwidth | 7°(Azimuth), 10°(Elevation) |
|---|
| Koruma | 15KV ESD Protection
6KV Lightning Protection |
|---|
| Muhafaza | Material: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design |
|---|
| KABLOSUZ ÖZELLİKLERİ |
|---|
| Kablosuz Standartlar | IEEE 802.11a/n |
|---|
| Tescilli Protokol | TDMA Mode (with Pharos MAXtream enabled) |
|---|
| Kablosuz Hızı | Up to 150Mbps (40MHz,Dynamic)
Up to 72.2Mbps (20MHz,Dynamic)
Up to 36.1Mbps (10MHz,Dynamic)
Up to 18.05Mbps (5MHz,Dynamic) |
|---|
| Frekans | 5.15~5.85GHz |
|---|
| İletim Gücü | Max. 23dBm (Adjustable power by 1dBm) |
|---|
| YAZILIM ÖZELLİKLERİ |
|---|
| IPv6 | Yes |
|---|
| Ağ Yapılandırma | WAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding |
|---|
| Kablosuz Konfigürasyonlar | Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Long Range PtP |
|---|
| Yönetim | Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server |
|---|
| Sistem Araçları | Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Antenna Alignment |
|---|
| Sistem Düzeyindeki Optimizasyonlar | Optimized IGMP Snooping/Proxy for multicast applications
|
|---|
| DİĞERLERİ |
|---|
| Sertifika | CE, FCC, RoHS, IP65 |
|---|
| Paket İçeriği | Outdoor Wireless CPE
24V 0.25A Passive PoE Adapter
Pole Mounting Kits
AC Power Cord
Installation Guide |
|---|
| Sistem Gereksinimleri | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended. |
|---|
| Ortam | Operating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing |
|---|
