WiFi AP Özellikleri
- 802.11 ac/n/a/g/b, 2.4 GHz & 5 GHz dual-band
- Auto Channel Select (ACS)
- WiFi Enabled Device #: up to 32
- Hidden SSID
- Security modes: Open, WPA2-PSK, WPA-PSK/WPA2-PSK
- AP power saving mode
- Access control: STA blacklist/white list
- MAC filtering
- Dual-SSID support
- WPS: Pin and PBC, WPS2.0
Sistem Özellikleri
- Web UI/multiple language supported
- SMS/Quota/APN/PIN management
- Network selection
- Data usage/statistic
- DHCP server
- Dynamic DNS
- IP/URL filtering
- NAT Port forwarding/trigger/ALG/DMZ
- IP firewall
- Proxy DNS
- VPN pass-through
- FOTA firmware upgrade
- TR-069 remote management
- USSD management
Desteklenen USB Bağlantı Sistemi
- Win XP, Win Vista, Win 7, Win 8, Win 10
- MAC OS X10.7, 10.8, 10.9, 10.10 , 10.11, 10.12, 10.13
- Ubuntu 12.04 LTS, 14.04 LTS
Browser Client
- Internet Explorer
- Edge
- Firefox
- Chrome
- Safari
LTE Air Arayüzü
- Standard compliant: 3GPP release 10, category 6
- Supported frequency: LTE B1/B3/B7/B8/B20/B28a/B38/B40/B41
- Carrier aggregation support:
- B1+B1/B3/B/B8/B20/B28a/38/40/41
- B3+B3/B7/B8/B20/28a/B38/B40/B41
- B7+B7/B8/B20/B28a
- B20+B38/40
- B38+B38, B40+B40, B41+B41
- FDD LTE peak data rate:
- 300 Mbps DL within 40 MHz bandwidth (CA)
- 50 Mbps UL within 20 MHz bandwidth
- TDD LTE peak data rate:
- 224 Mbps DL within 40MHz bandwidth (CA)
- 10 Mbps UL within 20 MHz bandwidth
UMTS Air Arayüzü
- Standard compliant: DC-HSDPA/ HSPA+ compliant
- Supported frequency: HSPA+/UMTS 2100/900 MHz (band 1/8)
- DC-HSPA+ downlink DL up to 42 Mbps
- HSUPA UL up to 5.76 Mbps
Donanım Arayüzü
- One 3FF/Micro SIM card slot
- One USB port for power supply or USB with RNDIS
- Reset button
- Power button
- Left, Home/OK, Right (touch sensing keys)
- DC input (5V/1.5A, Micro USB)
- 2.4-inch TFT display
- Service provider name
- 3G/4G network status
- Roaming status
- Signal strength
- Battery status
- WiFi status
Pil
- 3000 mAh Lithium-ion polymer, un-removable battery
- Up to 10 hours operating time*
- Up to 300 hours standby time*
- Item dimensions (WxDxH): 118.2 x 65 x 15.7 mm (4.65" x 2.56" x 0.618")
- Item weight: 130 g (0.29 lb.)
- Packing dimensions (WxDxH): 150 x 80 x 50 mm (5.90" x 3.15" x 1.97")
- Packing weight: 270g (0.59lb.)
Operating Environment
- Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 5% to 95% (Non-condensing)
Storage Environment
- Temperature: -20°C to 60°C (-4°F to 140°F)
- Humidity: 5% to 95% (Non-condensing)
- UN38.3
- CE: EMC/RF/SAR/Safety
- WiFi Alliance
- WEEE
- 2011/65/EC (RoHS) Restriction of
- Hazardous Substances Directive
- HSF (Hazardous Substance Free)
- European Parliament and Council
- Directive 94/62/EC of 20 December
- 1994 on packaging and packaging waste
